Datapoints for p + p + o15 -> he4 + o13
Back to rateCalculate Rate at a
Specific Temperature
Data Points for
Standard Temperatures
| Temperature | Value |
|---|---|
| 0.1 | 0.000000e+00 |
| 0.15 | 1.964924e-301 |
| 0.2 | 1.611786e-230 |
| 0.3 | 2.843401e-157 |
| 0.4 | 1.924435e-120 |
| 0.5 | 3.616849e-98 |
| 0.6 | 3.279210e-83 |
| 0.7 | 1.817669e-72 |
| 0.8 | 2.223770e-64 |
| 0.9 | 4.457329e-58 |
| 1 | 4.916270e-53 |
| 1.5 | 5.221847e-38 |
| 2 | 1.116387e-30 |
| 2.5 | 2.136366e-26 |
| 3 | 1.364051e-23 |
| 3.5 | 1.351316e-21 |
| 4 | 4.373424e-20 |
| 4.5 | 6.840875e-19 |
| 5 | 6.424776e-18 |
| 6 | 1.910213e-16 |
| 7 | 1.861762e-15 |
| 8 | 6.862528e-15 |
| 9 | 9.720832e-15 |
| 10 | 5.122609e-15 |
| View Graph | |
This material is based upon work supported in part by the U.S. Department of Energy, Office of Science, Office of Nuclear Physics, under Award Number DE-SC0026204.
