Datapoints for p + mn80 -> he4 + cr77
Back to rateCalculate Rate at a
Specific Temperature
Data Points for
Standard Temperatures
| Temperature | Value |
|---|---|
| 0.1 | 1.940445e-26 |
| 0.15 | 6.555359e-22 |
| 0.2 | 2.479150e-19 |
| 0.3 | 3.764463e-16 |
| 0.4 | 4.370100e-14 |
| 0.5 | 1.429233e-12 |
| 0.6 | 2.162855e-11 |
| 0.7 | 1.943673e-10 |
| 0.8 | 1.200104e-09 |
| 0.9 | 5.589729e-09 |
| 1 | 2.093124e-08 |
| 1.5 | 2.019060e-06 |
| 2 | 3.226795e-05 |
| 2.5 | 2.238301e-04 |
| 3 | 9.977041e-04 |
| 3.5 | 3.440914e-03 |
| 4 | 1.010485e-02 |
| 4.5 | 2.661402e-02 |
| 5 | 6.470046e-02 |
| 6 | 3.180484e-01 |
| 7 | 1.267379e+00 |
| 8 | 4.117321e+00 |
| 9 | 1.077611e+01 |
| 10 | 2.232656e+01 |
| View Graph | |
