Datapoints for p + tb172 -> he4 + gd169
Back to rateCalculate Rate at a
Specific Temperature
Data Points for
Standard Temperatures
| Temperature | Value |
|---|---|
| 0.1 | 2.864882e-168 |
| 0.15 | 7.022704e-105 |
| 0.2 | 5.299380e-73 |
| 0.3 | 9.105647e-44 |
| 0.4 | 8.934075e-32 |
| 0.5 | 4.355738e-26 |
| 0.6 | 4.154939e-23 |
| 0.7 | 2.124008e-21 |
| 0.8 | 2.578692e-20 |
| 0.9 | 1.529368e-19 |
| 1 | 6.386942e-19 |
| 1.5 | 2.798310e-16 |
| 2 | 1.429047e-13 |
| 2.5 | 5.508561e-11 |
| 3 | 9.566521e-09 |
| 3.5 | 6.221735e-07 |
| 4 | 1.539215e-05 |
| 4.5 | 1.623904e-04 |
| 5 | 8.546792e-04 |
| 6 | 5.802171e-03 |
| 7 | 1.786298e-02 |
| 8 | 7.871650e-02 |
| 9 | 1.297746e+00 |
| 10 | 1.766928e+02 |
| View Graph | |
