Datapoints for he4 + w190 -> p + re193
Back to rateCalculate Rate at a
Specific Temperature
Data Points for
Standard Temperatures
| Temperature | Value |
|---|---|
| 0.1 | 0.000000e+00 |
| 0.15 | 0.000000e+00 |
| 0.2 | INFe-316 |
| 0.3 | 4.535446e-204 |
| 0.4 | 2.237714e-150 |
| 0.5 | 1.015225e-119 |
| 0.6 | 3.201319e-100 |
| 0.7 | 7.710910e-87 |
| 0.8 | 4.152532e-77 |
| 0.9 | 1.070670e-69 |
| 1 | 7.808060e-64 |
| 1.5 | 6.432270e-46 |
| 2 | 8.945990e-36 |
| 2.5 | 1.249230e-28 |
| 3 | 3.717638e-23 |
| 3.5 | 7.954278e-19 |
| 4 | 2.326129e-15 |
| 4.5 | 1.412838e-12 |
| 5 | 2.434215e-10 |
| 6 | 4.324585e-07 |
| 7 | 6.386323e-05 |
| 8 | 2.615333e-03 |
| 9 | 7.674486e-02 |
| 10 | 3.461081e+00 |
| View Graph | |
